F-1002MLJ, Flaker Icemaker, Low Side Remote-cooled

Dimensions: 22″ W x 27-3/8″ D x 25-15/16″ H
Up to 1028 lbs of ice produced per 24 hours
Mount 2 units side-by-side for 2x the ice production
Produces flaked ice
Durable stainless steel exterior
Compatible bins & dispensers, sold separately: B-250, B-300, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500SS, B-1650SS, B-1150, B-1300, B-1500SS, B-1650SS
2 second rinse every hour to remove sediment
Advanced CleanCycle24™ design
Protected by H-GUARD Plus Antimicrobial Agent
R-404A refrigerant ( / )
Heat Rejection: BTU/hr
Ambient temperature range: 45 – 100°F
Water temperature range: 45 – 90°F
Water pressure: 10 – 113psig
Voltage range: 104 – 127V
3.3 amps (15 Amp Max fuse)
1.51 kwh/100 lbs.@ 90/70
Single phase, 115v/60/1,
Clean ice and easy maintenance lead to longer unit life span
Three Years: Parts & Labor warranty on entire machine.
Five Years: Parts warranty on Compressor, air-cooled condenser coil.

SKU: F-1002MLJ Categories: Flaker, Ice, Ice Maker, Low Side Remote AC, Modular

Resources

Videos

Description

The F-1002MLJ is capable of producing approximately 1028 lbs of flaked ice per day. Flaked ice is perfect for salad bars, seafood counters, and other food displays that require long lasting sanitary ice. This Low Side Remote, Modular, Low-Side Series icemaker features the Advanced CleanCycle24™ design plus a greaseless bearing auger construction making it simple to maintain. The F-1002MLJ requires a Single phase, 115v/60/1, electrical connection that is hard-wired at the installation site. Compatible bins & dispensers, sold separately: B-250, B-300, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500SS, B-1650SS, B-1150, B-1300, B-1500SS, B-1650SS. Please consult the Specification Sheet for additional details.

Additional Information

Weight	150 lbs
Dimensions	33 × 25.25 × 32 in
height	25.9375
width	22
depth	27.375
shipping-weight	150
warranty	Three Years: Parts & Labor warranty on entire machine.
certifications	NSF, UL Listed
energy-star-qualified	No
electrical-specs	Single phase, 115v/60/1 , Amperage: 3.3, Max Fuse/HACR Breaker: 15 A
plumbing-specs	1/2" FPT Inlet, Minimum 1/4" Nominal ID Copper Water Tubing or Equivalent, 3/4" FPT Outlet, Minimum 3/4" Nominal ID Hard Pipe or Equivalent
utility-consumption	1.51 kWh per 100 lbs @ 90/70, 12 gal of Potable Water per 100 lbs @ 90/70
operating-limits	Ambient Temp Range: 45 – 100°F, Water Temp Range: 45 – 90°F, Water Pressure: 10 – 113psig, Voltage Range: 104 – 127V, Heat Rejection: BTU/hr, Refrigerant Charge: R-404A, ( / )
